ESWT Shockwave Therapy Machine BS-SWT5000

ESWT Shockwave Therapy Machine BS-SWT5000, for physical therapy purpose.


ESWT Shockwave Therapy Machine

Model: BS-SWT5000

Shock wave is one of the few medical technologies that performs best on people with chronic conditions that did not respond to conservative traditional therapy, when compare to laser therapy, ultrasonic therapy or even ozone therapy. Shock wave accelerates the body’s own healing process as a purely physical treatment method: Through a process called cavitation, shock wave stimulates fibroblast and tenocyte production of human body. Fibroblast or tenocyte cells make up human bodies' connective tissues, such as tendons and the fascia. Shock wave diminishes pain by over-stimulating the nerves that send pain sensations to the brain. The procedure can break down pathological calcification deposits (well known as a spur on feet). Shock wave is targeted at the condition that caused the spur, not the spur itself, so it can treat the chronic pain thoroughly.

BS-SWT5000 is the latest designed as Extracorporeal Shockwave Equipment useful for:

• Tendopathia

• Musculoskeletal pain after sports

• Heel Spur / Fascitis Plantaris

• Epicondylopathia radialis / ulnaris

• Patella Tip Syndrome / Achillodynia

• Myofascial Pain Syndromes

• Tibialis anterior Syndrome

• Impingement Syndrome

• Trigger Point Therapy

• Diabetic foot

BS-SWT5000 is made of fully metal (high-quality Aluminum alloy), total weight is over 17Kg for the main unit, providing long time stable output (1-5Bar, 0.1Bar adjustable, 1-22Hz).

Rich pre-set protocols, as well as other functions can be easily used for various indications. It comes with 6 fully metal made transmitters, durable and high energy-transfer rate.



Energy levels1 to 5Bar, adjustable stepping at 0.1Bar
Pulse frequencies1 to 22 Hz
Burst modes3 burst modes or continuous
Transmitter diameter35mm 6mm, 20mm, 15mm Flat/Unfocused/Focused
Built-in programs 40 pre-set protocols
Working Environment10 – 28ºC 30~80%RH,500~1060hPa
Power SpecificationAC110V or 220V/50Hz – 60Hz, 16A
